Applicable Standard
Design Standard: API 609, MSS SP-67, MSS SP-68, BS 5155
Face to Face: API 609, ASME B16.10, BS 5155, EN1092
End Connection: ASME B16.5, ASME B16.47
Inspection and Test: API 598
Products Range
Size: 2" ~ 36" (DN50 ~ DN900)
Rating: ANSI 150lb ~ 600lb
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel.
Disc Sealing: PTFE, Graphite Laminated
Operation: Lever, Gear, Electric, Pneumatic, Hydraulic
Design Features
Triple eccentric or double eccentric design
Metal to metal seated
Bi-directional service
Frictionless closure
Blow-out proof shaft
Wafer, wafer-lug, double flange ends
ISO top flange
